Hydraulic Component
- Application
- • Various oil brake system application (Lining type, Disc type)
- • Adjustable torque of hydraulic brake
- • Hydraulic brake with anti-backlash
- • It is applied in various fields with low noise and long life.
- Specifications
-
| MODEL |
YHB40 |
YHB60 |
YHB80 |
YHB130 |
| Brake Torque |
400 N.m |
600 N.m |
800 N.m |
1,300 N.m |
| Max. Pressure |
350 bar |
350 bar |
350 bar |
350 bar |
| Opening Pressure |
20 bar |
20 bar |
25 bar |
25 bar |
| Port |
PF 1/4 |
PF 1/4 |
PF 1/4 |
PF 1/4 |
| Weight |
18 kg |
27 kg |
36 kg |
55 kg |
