Winch equipment

HOME > Business > Winch equipment

Application
Marine ship-building and off-shore equipments
Construction equipments
Industrial equipments
Conveyance(lifting, hoist) equipments
Agricultural machine equipments
Mining equipments
Airport and Railway equipments
Specifications
Pump Size 45cc 55cc 65cc 80cc 90cc 107cc
Displacement
(cm3/rev)
44.2 54.6 65 80.3 90.4 106.6
Working pressure
[bar]
250 250 250 250 250 250
Max. pressure
[bar]
350 350 350 350 350 350
Peak pressure
[bar]
420 420 420 420 420 420
Max. speed
[rpm]
2,200 2,000 2,000 1,800 1,800 1,600
Pump rotation speed
(Increasing the suction pressure) [rpm]
3,600 3,500 3,500 3,250 3,250 3,000
Max. flow [l/m] 97 108 130 144 162 170
Max. torque [N.m] 246 303 362 447 504 593
Max. power(kw) 55 62 74 82 93 97
Weight [kg] 21 21 28.8 28.8 40.5 40.5
Connection Port S : SAE 1"
 (3000psi)
S : SAE 1 1/4"
(3000psi)
S : SAE 1 1/2"
(3000psi)
A(B) : SAE 3/4“
(6000psi)
A(B) : SAE 1“
(6000psi)
A(B) : SAE 1 1/4"
(6000psi)
