Winch equipment

HOME > Business > Winch equipment

Application
Marine ship-building and off-shore equipments
Construction equipments
Industrial equipments
Conveyance(lifting, hoist) equipments
Agricultural machine equipments
Mining equipments
Airport and Railway equipments
Specifications
Motor Size 45cc 55cc 65cc 80cc 90cc 107cc
Displacement
(cm3/rev)
44.2 54.6 65 80.3 90.4 106.6
Working pressure
[bar]
250 250 250 250 250 250
Max. pressure
[bar]
350 350 350 350 350 350
Peak pressure
[bar]
420 420 420 420 420 420
Max. speed
[rpm]
4,400 3,900 3,900 3,450 3,450 3,000
Max. flow
[l/m]
194 213 253 276 312 320
Max. torque
[N.m]
246 304 362 448 504 594
Max. power(kw) 111 121 145 158 178 183
Weight [kg] 21 21 28.8 28.8 40.5 40.5
Connection Port A : SAE 3/4“
(6000psi)
A : SAE 1“
(6000psi)
A : SAE 1 1/4“
(6000psi)
B : SAE 3/4“
(6000psi)
B : SAE 1“
(6000psi)
B : SAE 1 1/4“
(6000psi)

See the video clip
