유압 부품
- 특징
- • Various oil brake system application (Lining type, Disc type)
- • Adjustable torque of hydraulic brake
- • Hydraulic brake with anti-backlash
- • It is applied in various fields with low noise and long life.
- 스펙
-
MODEL YHB40 YHB60 YHB80 YHB130 Brake Torque 400 N.m 600 N.m 800 N.m 1,300 N.m Max. Pressure 350 bar 350 bar 350 bar 350 bar Opening Pressure 20 bar 20 bar 25 bar 25 bar Port PF 1/4 PF 1/4 PF 1/4 PF 1/4 Weight 18 kg 27 kg 36 kg 55 kg
